U-12 U type shackle factory supply

U-shaped hanging rings (often UL extended type) are one of the most basic connecting hardware in overhead power lines, and are widely used for connecting poles, insulator strings, and steel strands.The U-12 is a U-shaped ring series connecting fitting with a nominal breaking load of 120kN (12-ton class).

Material:

The U-shaped main body is made of high-quality carbon structural steel with a tensile strength ≥372.5MPa, meeting the long-term mechanical tensile requirements of power lines; Pins/Bolts: Carbon steel of the same material;

Cotter Pins: Stainless steel

Key performance parameters (U-12)

Core uses and application scenarios

The U-12, as a general-purpose connecting hardware for medium and high loads, is widely used in the following scenarios:

* **Insulator String Connection:** In 110kV/220kV suspension and tension strings, it connects insulators to crossarms/towers, transmitting mechanical tension.

* **Combined with right-angle hangers and cup-head hangers to form complete suspension/tension string assemblies.**

* **Guard Wire System Fixing:** Connects guard wire clamps, steel strands, and tower foundations, bearing guard wire tension; suitable for long-span, high-tension lines.

* **Substation Hardware Connection:** Used in outdoor power distribution equipment, connecting busbars, equipment clamps, and frames to transmit equipment loads.

* **String Extension Use:** Multiple U-12s can be connected in series, or combined with UL-12 extension hangers to adjust the insulator string length to adapt to different installation distances.

Additional information: U-12 vs UL-12

U-12: Standard length, used for connections over normal distances.

UL-12: Extended type (L=Long), longer in length, used for scenarios requiring increased connection distance or adjustment of string length. Both have the same destructive load; only the dimensions are adapted to different installation needs.
